| Spool | Description | Size | Length mm | Source object |
|---|---|---|---|---|
| SP-03-014 | CHW supply, 150mm | 150 | 4,820 | Pipe: CHW-S-150 |
| SP-03-015 | CHW return, 150mm | 150 | 4,640 | Pipe: CHW-R-150 |
| SP-03-022 | Condenser water riser | 200 | 6,100 | Pipe: CW-R-200 |
| SP-04-007 | Supply duct, rect. | 600×400 | 3,200 | Duct: SA-R-600 |
| SP-04-011 | Sprinkler main | 100 | 5,400 | Pipe: FP-M-100 |
| SP-05-003 | Hanger run, trapeze | — | 2,750 | Support: TR-05 |
| SP-05-009 | Extract duct, spiral | 400 | 3,980 | Duct: EA-S-400 |
| SP-06-001 | Steam header | 80 | 2,410 | Pipe: ST-H-080 |
| SP-06-004 | Chilled beam branch | 50 | 1,860 | Pipe: CB-B-050 |

We take the approved coordination model to LOD 350–400 and produce the packages your shop needs — spools, isometrics, hanger schedules, cut lists and CNC-ready output.
We work in your stack
Three packages come off one approved model. The drawing and the quantity cannot disagree, because both are generated from the same objects.

Spool drawings and isometric views are generated from the model, with weld maps, so the shop works from geometry that was coordinated rather than geometry that was redrawn.
Hangers are placed against the structure that exists in the model, not where the structure was assumed to be, and scheduled with the supports they carry.
Material cut lists and fabrication files in your shop's formats, so the output feeds the machine instead of being retyped into it.

Connections detailed against your own standards and your connection library, with engineer review before anything leaves.
The erection sequence drawn and scheduled, with member and bolt lists generated from the same model the drawings came from.
DSTV / NC1 straight out of Tekla, so the fabrication file and the drawing describe the same member rather than two versions of it.

Panel drawings produced from the model with cast-in items and lifting points carried through, rather than added back on the drawing afterwards.
Reinforcement modelled and detailed to your bending schedules, laps and cover requirements.
Schedules generated from the model rather than retyped from it, so a change to the geometry moves the schedule with it.
Take the approved coordination model
Detail to LOD 350–400 against your standards
Generate spools, schedules and cut lists
Release CNC-ready output, engineer-checked

Send us an approved coordination model.
Nothing here asks your shop to change how it works. Your detailing rules, connection library, tolerances and output formats are captured at intake and held to on every package.
Model, detail, generate, release
Every drawing generated from the object it describes.
Detailing rules, connection library, tolerances.
Tekla, Revit, Navisworks, AutoCAD, SDS/2, IFC.
DSTV / NC1, DWG — the files your machines read.
